Specifications
| Display Accuracy | 0.1μm |
| show | 2-Inch wide Viewing Angle omnidirectional IPS-TFT color liquid crystal |
| Power Supply | 2xAA alkaline battery |
| battery life | Meet 40,000 previous measurements |
| statistical function | Average, MAX Maximum, MIN Minimum, Standard deviation |
| Dimensions (length x width x thickness) | 135×63×43 mm |
| net Weight | 100 g |
| operating temperature | 0℃~+50℃ |
| Storage temperature | -20℃~+70 ℃ |
| Relative Humidity | 10%~90% |
| Measurement Range | 3mm |
| measurement speed | ≥ 100/min |
| Measurement Accuracy (Fe mode) | +/- (1 μm + 2% reading) @0-2mm or +/- 5% reading @> 2mm |
Packing list
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47044/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
