Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception), SCI/SCE measurement conforms to CIE No. 15, GB/T3978, GB2893, GB/T18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | φ40mm |
| lighting source | Light spectrum LED light source |
| spectroscopic mode | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 32 groups) |
| Measurement Wavelength range | 400～700nm |
| wavelength interval | 10nm |
| Half bandwidth | 10nm |
| Measurement range | L: 0~120 reflectance: 0~200% |
| Measurement caliber | Single diameter: phi 8mm/phi 10mm |
| Light-containing method | Simultaneous testing of SCI/SCE |
| Color Space | CIE LAB，XYZ，Yxy，LCh，s-RGB，βxy，Munsell(C/2) |
| color difference formula | △E*ab，△E*94，△E*cmc(2:1)，△E*cmc(1:1)，△E*00，DIN△E99 |
| Miscellaneous chroma index | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), homochromatic index Mt, colour fastness, fastness to color change, force, coverage, Formula Guide |
| Observer Angle | 2°/10° |
| observation light source | D65，A，C，D50，F2(CWF)，F7(DLF)，F10(TPL5)，F11(TL84)，F12(TL83/U30) |
| show | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, pass/fail results, Color simulation, Color bias |
| Measurement time | Approximately 1.5s (approximately 3.2s for simultaneous SCI/SCE testing) |
| Sexual repeability | Chromatic value: MAV/SCI, Delta E * ab within 0.06 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) |
| Inter-instrument Agreement | MAV/SCI, Delta E * ab within 0.3 (BCRA series ⅱ 12 color plate measurement average) |
| Measurement method | Single measurement, average measurement (2~ 99 times) |
| positioning method | Display camera viewfinder positioning, stabilizer positioning |
| size | Length X width X height = 81X71X214mm |
| Weight | Approx. 500g |
| Battery level | Lithium battery, 6000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| interface | USB |
| store data | 1000 master standards, 20,000 samples (one data can include SCI/SCE at the same time) |
| language | Simplified Chinese, English, Traditional Chinese |
| Operating temperature range | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage temperature range | -20~50 ℃. 0~85% RH (no condensation) |
| standard attachment | power adapter, data cable, manual, SQCX quality management software, black and white correction box, protective cover, wristband, 08mm platform diameter, 08mm pointed diameter |
| optional accessories | USB micro printer, powder test box |
Packing list
host X1, manual x1, certificate of conformity x1, warranty card x1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
