Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception), SCI/SCE measurement conforms to CIE No. 15, GB/T3978, GB2893, GB/T18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| Integrating sphere size | φ40mm |
| lighting source | Light spectrum LED light source, UV light source |
| spectroscopic mode | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 32 groups) |
| Measurement Wavelength range | 400～700nm |
| wavelength interval | 10nm |
| Half bandwidth | 10nm |
| Measurement range | L: 0~120 reflectance: 0~200% |
| Measurement caliber | Dual diameter: MAV: φ 8mm/φ 10mm, SAV: φ 4mm/φ 5mm |
| Light-containing method | Simultaneous testing of SCI/SCE |
| Color Space | CIE LAB，XYZ，Yxy，LCh，CIE LUV，s-RGB，βxy，DIN Lab99 Munsell(C/2) |
| color difference formula | △E*ab，△E*uv，△E*94，△E*cmc(2:1)，△E*cmc(1:1)，△E*00 |
| Miscellaneous chroma index | WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), homochromatic index Mt, colour fastness, fastness to color change, force, coverage, Formula Guide |
| Observer Angle | 2°/10° |
| observation light source | D65，A，C，D50，D55，D75，F1，F2(CWF)，F3，F4，F5，F6，F7(DLF)，F8，F9，F10(TPL5)，F11(TL84)，F12(TL83/U30) |
| show | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, pass/fail results, Color simulation, Color bias |
| Measurement time | Approximately 1.5s (approximately 3.2s for simultaneous SCI/SCE testing) |
| Sexual repeability | Chromatic value: MAV/SCI, Delta E * ab within 0.05 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) |
| Inter-instrument Agreement | MAV/SCI, Delta E * ab within 0.3 (BCRA series ⅱ 12 color plate measurement average) |
| Measurement method | Single measurement, average measurement (2~ 99 times) |
| positioning method | Display camera viewfinder positioning, stabilizer positioning |
| size | Length X width X height = 81X71X214mm |
| Weight | Approx. 500g |
| Battery level | Lithium battery, 6000 cycles in 8 hours |
| Lighting source life | More than 3 million measurements in 5 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| interface | USB, Bluetooth 5.0 |
| store data | 1000 master standards, 30,000 samples (one data can include SCI/SCE at the same time) |
| language | Simplified Chinese, English, Traditional Chinese |
| Operating temperature range | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage temperature range | -20~50 ℃. 0~85% RH (no condensation) |
| standard attachment | Power adapter, data cable, manual, SQCX quality management software (official website DOHO.cn download), black and white correction box, protective cover, wristband, 08mm platform diameter, 08mm pointed diameter, 04mm platform diameter, 04mm pointed diameter |
| optional accessories | USB micro printer, powder test box, Bluetooth micro printer |
Packing list
host X1, manual x1, certificate of conformity x1, warranty card x1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47096/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
