Specifications
| Coating method | Smoothing Rods Spreader |
| Coating size | 300 * 400Mm (can be customized) |
| application width | 300mm |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Control mode | Touch screen control |
| Regulator display Accuracy | ±0.001mm |
| Display | digital display |
| Total power consumption | 2060W |
| Host Power Supply | 220V 50Hz |
| Dimension | 690*410*520mm |
| Machine Weight | 65Kg |
| Coating table material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Smoothing Rods Adjustable Thickness Range | 0~10mm |
| speed control | Infinitely variable speed |
| Substrate clamping method | Vacuum adsorption |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator X1, Adjustable Thickness Smoothing Rods X1, Product Manual X1
After-sales instructions
Warranty days: 365 days
