Specifications
| Coating Method | Drawdown blade + UV curing |
| Drawdown blade type | Drawdown blade |
| Drawdown blade material | 304 stainless steel |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Drawdown blade Coating thickness range | 0~ 10Mm adjustable |
| Coating Speed | 5~ 200Mm/s (< 5mm/s can be customized) |
| Effective coating Area | 400 * 300Mm (can be customized) |
| Spreader Itinerary | Digital arbitrary setting within the range of 1~ 400mm |
| Vacuum Area | 400 * 300Mm (can be customized) |
| Vacuum aperture diameter | Φ1.2mm |
| Vacuum hole pitch | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Host power supply | 220V 50Hz |
| Dimension | 630*410*520mm |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| UV curing area | 400*300mm |
| UV light main peak wave | 365nm |
| UV Light Power | 800W |
| UV light curing wavelength | 350~450nm |
| UV UV Lamp Spacing | 18*18mm |
| Substrate clamping method | Vacuum chuck |
| Control mode | Touch screen control |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator X1, External vacuum pump (oil pump) X1, Drawdown blade X1, UV light curing device x1 set, product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47140/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
