Specifications
| Effective Spreader Width | 200mm |
| Effective Spreader Length | 2m |
| Casting rate | 80-500mm/min continuously adjustable |
| Spreader Film thickness range | 0.1~ 0.6Mm adjustable |
| Screw diameter | 25mm |
| Screw aspect ratio | 28mm |
| Screw speed | 0-120rpm |
| die width | 200mm |
| Roll surface width | 200mm |
| linear velocity | 0-5m/min |
| Pressure Measurement Range | 0-50mpa |
| Pressure measurement Accuracy | 0.5%f.s |
| Heating method | Electric heating |
| Chill down | fan |
| Temperature control Accuracy | ±1℃ |
| Maximum yield | 3kg/h |
| Main motor power | 3kw |
| Control system | SIEMENS PLC control |
| Working Voltage | Three-phase 380VAC + 10%, single-phase 220VAC + 10%, 50HZ |
| rated power | About 10kw |
| Dimensions | 2105*860*1585mm |
| Machine Weight | About 600kg |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47142/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
