Specifications
| Coating method | Drawdown blade |
| Drawdown blade type | Integrated drawdown blade |
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0.001~ 10Mm adjustable |
| Coating speed | 5~ 200Mm/s (< 5mm/s can be customized) |
| Coating size | 400 * 400Mm (can be customized) |
| Drawdown blade material | 304 stainless steel |
| Length of drawdown blade | 400mm |
| Host Power Supply | 220V 50Hz |
| Bracket height adjustment range | 0~5cm |
| Net Weight | Subject to the actual product |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Control mode | Touch screen |
| Vacuum Area | 400 * 400Mm (can be customized) |
| vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Automatic Film Applicator x1, casting knife x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47247/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
