Specifications
| Spreader process | Unwinding → scraping → drying → air cooling → fitting → correction → winding |
| Coating method | Drawdown blade |
| Film thickness range | 0.005-2mm |
| Film Accuracy | ±5% |
| Graduation | 0.001mm |
| percentile | digital display |
| Coating speed | 0-20M/min adjustable |
| Spreader roller heating | Upper and lower roller oil temperature heating |
| Spreader roller heating range | RT+~150 ℃ |
| Storage board heating range | RT+~100 ℃ |
| Unwinding outer diameter | 400mm |
| Effective Spreader Width | ≤300mm |
| Roll surface length | 350mm |
| Oven length | 2m |
| Oven temperature range | RT+~150℃ |
| Air cooling device | √ |
| Ventilation device | √ |
| Box roll material | Teflon material |
| winding outer diameter | 300mm |
| Effective Spreader Width | ≤300mm |
| compound speed | 1~10m/min |
| Composite Accuracy | 0.5mm |
| composite width | 100~300Mm adjustable |
| Outer diameter of winding air expansion shaft | ≥150mm |
| Winding outer diameter range | ≤500mm |
| Dimensions | 5080Mm * 600mm * 1600mm (subject to actual customization) |
| Host Power Supply | 380V/2KW |
Packing list
Automatic Film Applicator x1, film device x1, drying device x1, rewinding and rewinding device x1, deviation correction device x1, bonding device x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47249/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
