Specifications
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Drawdown blade Spreader Film thickness range | 0~10Mm drawdown blade can be lifted |
| Coating Speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Effective coating Area | 400*300mm |
| Host Power Supply | 220V 50Hz |
| speed control | Infinitely variable speed |
| Coating table material | Glass plate |
| Intelligent program control | Support computer remote setting film speed, film length, film temperature |
| communication interface | USB |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2~150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the operating speed of the discharge port) |
| Shaft transmission mode | Timer belt |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-equipped) |
| Feeding system power Voltage | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| optional accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven film thickness of Spreader substrate), film width control baffle |
| customizable function | Jet system device, UV solid inclusion device |
| Coating Method | Drawdown blade Spreader |
Packing list
Automatic Film Applicator X1, drawdown blade X1, automatic feeding system x1, remote control software x1, product manual X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47250/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
