Specifications
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0.02~ 10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*600mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 600 * 900Mm (can be customized) |
| vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
| drawdown blade | length |
| Host Power Supply | 220V 50Hz |
| Weight | Subject to the actual product |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Jet system device, UV solid inclusion device, automatic inking system |
Packing list
Film Applicator X1, External vacuum pump X1, doctor blade X1, product manual X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47253/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
