Specifications
| Coating method | scraping |
| Coating speed | 1~10m/min |
| application width | 100-500Mm adjustable |
| WFT | 0.005-3mm |
| Device size | About length 4000X width 800X height 1600mm (subject to actual customization) |
| maximum discharge | 500mm |
| Maximum charge | 500mm |
| Effective application width | 500mm |
| Drying channel length | 1m |
| Drying Power | 1KW |
| Power/Power | 220V/2.5KW |
| rubber roller | Heating temperature: room temperature~ 200 ℃ |
| Spreader head | Adjustable doctor blade Spreader |
| Coating size | Max.500mm |
| Feeding method | Automatic feeding (barrel with heating and stirring function)) |
Packing list
Host x1, Spreader head x1, automatic feeding system x1, manual x1, certificate of conformity x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47381/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
