Specifications
| main substrate | PET or other non-breakable materials |
| glue | Water-based paints, solar-based paints |
| Spreader moisture | Adjustable according to the process (thousand head adjustment control thickness) |
| Coating method | scraping |
| Coating size | Max.300mm |
| substrate | Less than 300mm |
| Roll surface width | 300mm |
| Mechanical speed | 1.2M/min (0.1~ 1m/min production speed, depending on the process) The speed can be adjusted slowly |
| unwinding diameter | ≤ φ 100mm (paper core 3 ") |
| winding diameter | ≤ φ 100mm (paper core 3 ") |
| Curing method | Bathing film formation |
| Reel the edges neatly | ±3.0mm |
| Total Installed Power | About 1000W (Power required for electric heating about 1000W) |
| Equipment external Dimensions | (L x W x H) According to process changes and final design drawings |
| Teflon roller | 4 pieces (installed in front of the Spreader head) |
| Power Supply | Three-phase five-wire 380V 50Hz |
| Unwinding Unit - Type | Single station |
| Unroll Unit - Effective Unroll Width | 300mm |
| Unwinding Unit - Effective Unwinding Diameter | ≤Φ100mm |
| Unwinding Unit - Unwinding Scroll | 3 " (φ 76mm) 1 piece of inflatable shaft (suspended wall structure) |
| Unwinding Unit - Unwinding Tension Control | Automatic tension control, magnetic particle brake, tension Controller |
| Front Traction Unit - Steel Roller | Φ42x500mm |
| Front Traction Unit - Motor | SEND/0.75KW (step-by-step control) |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47382/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
