Specifications
| Operating temperature range | -20~40°C |
| Temperature Fluctuation | ±0.5K |
| Temperature display | TFT display with Accuracy 0.01 ℃ |
| Heating power | / |
| cooling Capacity | 4000W |
| Maximum pump pressure | 0~ 0.7 adjustable bar |
| pump maximum suction | 0~ 0.4 adjustable bar |
| Flow rate of pump | 0~33.3 Adjustable L/min |
| Sink Volume | 20L |
| Dimensions (WxDxH) | 450X550X1150mm |
| Insulation pipe | Standard silicone insulation pipe 1.8m x 2 pieces |
| Communication interface | Optional RS232/USB |
| Low level alarm | optional |
| Heating function | optional |
| Power supply Voltage/Frequency | 220V/50Hz |
| Environmental humidity | 5~32 |
| Interface size | RC1/2 (4-point inner teeth) |
| Weight | 114kg |
| Packaging Dimensions (WxDxH) | 520*625*1335mm |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
