Specifications
| display | 10 inch 1024 × 800 high resolution capacitive touch LCD screen |
| Optical inspection system | Proportional double beam of light, CT monochromator |
| Wavelength range | 190~1100nm |
| focal length | 160mm |
| grating | 1600 lines/mm |
| Light source | Imported deuterium lamp, tungsten lamp |
| receiver | Imported photodiode |
| stray light | 0.03%（220nm） |
| wavelength setting | touchscreen input |
| Light spectrum Bandwidth | 1.8nm |
| Wavelength Accuracy | Full wavelength 0.2nm (656.1nm 0.1nm) |
| Wavelength Repeatability | 0.1nm |
| Wavelength scanning speed | Fast, medium, slow. |
| Transmittance Precision | 0.3%T |
| Transmittance Repeatability | ≤ 0.10%T |
| Light source switching wavelength | 340Nm (adjustable) |
| Photometric Range | 0.0~200.0%T -0.301~4.000A 0.000~9999C |
Packing list
After-sales instructions
Warranty days: 365 days
