DUBAN DB22-VM260B Vibrator, three-parameter display, displacement 0.001~ 4.0mm

DB22-VM260B

Vibrator

Sensors: Piezoelectric Vibration Sensors, Precision +/- 5% + 2 words, Measurement range Displacement: 0.001~ 4.0mm peak-peak; Speed: 0.01~ 400.0 m/s True RMS; Acceleration: 0.1~ 400 m/s ² peak; Frequency: 1~ 20,000Hz, Frequency range displacement: 10Hz~ 1KHz; Speed: 10Hz~ 1KHz.

Introduction

The DB22-VM260B vibrometer can display three measurement parameters at the same time: "Displacement", "Velocity" and "Acceleration"; It is applied to periodic motion measurement to detect imbalances and deviations in moving machinery. Designed for on-site measurement of a wide range of mechanical vibrations to provide data for quality control, uptime and prior equipment maintenance. Choose a high-performance accelerometer for accurate, reproducible measurements.

Features

• It is possible to display the three measurement parameters "Displacement", "Velocity" and "Acceleration" at the same time.

• Compliant with international standards ISO2954 for periodic motion measurement to detect imbalances and deviations in moving machinery.

• Designed for on-site measurement of a wide range of mechanical vibrations to provide data for quality control, uptime and prior equipment maintenance.

• Wide frequency range, in acceleration mode, the frequency can reach 10-10KHz.

• Piezoelectric accelerometers are used to convert them into vibration signals.

• It has the function of bearing condition measurement.

• With AC signal output, it is convenient for auscultation and recording.

• An optional headset can be used as a stethoscope.

• It uses "USB cable output" to communicate with the PC.

Packing list：Host X1, magnetic suction seat X1, probe (tapered) X1, probe (spherical) X1, measurement Sensors X1, portable case X1, instruction manual X1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
