DUBAN DB22-VM260A Vibration instrument, displacement D 0.001~ 4.0mm
SE
DB22-VM260A
Duban DB22-VM260A VibratorSPEC
Duban DB22-VM260A VibratorDetails
Duban DB22-VM260A VibratorPacking list
- SKU
- NB047433
- Measurement range
- Displacement D: 0.001~ 4.0mm (peak-to-peak P-P); Speed V: 0.01~ 400.0 mm/s (true RMS); Acceleration A: 0.1~ 400 m/s ² (peak P); Frequency: 1~ 20,000Hz
- Frequency range
- Displacement D: 5Hz~ 1KHz; Speed V: 5Hz~ 1KHz; Acceleration A: 5Hz~ 10KHz
- operating conditions
- Temperature: 0~50 ℃; Humidity: < 90%
- output
- 2.0V AC load resistance 10k
- size
- 140x77x32mm
- Power Supply
- 4X1.5vAAA 7 batteries
- Sensors
- Piezoelectric Vibration Sensors
- Precision
- +/- 5% + 2 words
Introduction
DB22-VM260A series vibrometers are used in periodic motion measurements to detect imbalances and deviations in moving machinery. Designed for on-site measurement of a wide range of mechanical vibrations to provide data for quality control, uptime and prior equipment maintenance. Choose a high-performance accelerometer for accurate, reproducible measurements.
Features
Compliant with international standards ISO2954 for periodic motion measurement to detect imbalances and deviations in moving machinery.
Designed for on-site measurement of a wide range of mechanical vibrations to provide data for quality control, uptime and prior equipment maintenance.
Wide frequency range, in acceleration mode, the frequency can reach 5-10KHz.
Piezoelectric accelerometers are used to convert them into vibration signals.
It has the function of bearing condition measurement.
With AC signal output, it is convenient for auscultation and recording.
An optional headset can be used as a stethoscope.
It uses "USB cable output" to communicate with the PC.
Serial models
| Model | DB22-VM260A | DB22-VM260A8 | DB22-VM260A12 | DB22-VM260A16 | DB22-VM260A20 |
| Measuring range | Displacement D: 0.001~4.0mm (peak-peak P-P) | Displacement D: 0.001~8.0mm (P-P) | Displacement D: 0.001~12.0mm (peak-peak P-P) | Displacement D: 0.001~16.0mm (peak-peak P-P) | Displacement D: 0.001~20.0mm (peak-peak P-P) |
| Speed V: 0.01~400.0mm/s (RMS) | Speed V: 0.01~800.0mm/s (RMS) | Speed V: 0.01~1200.0mm/s (RMS) | Speed V: 0.01~1600.0mm/s (RMS) | Speed V: 0.01~2000.0mm/s (RMS) | |
| Acceleration A: 0.1~400m/s² (peak P) | Acceleration A: 0.1~800m/s² (peak P) | Acceleration A: 0.1~1200m/s2 (peak P) | Acceleration A: 0.1~1600m/s² (peak P) | Acceleration A: 0.1~2000m/s² (peak P) | |
| Frequency: 1~20,000Hz | |||||
| Frequency range | Displacement D: 5Hz~1KHz | ||||
| Speed V: 5Hz~1KHz | |||||
| Acceleration A: 5Hz~10KHz | |||||
| Operating conditions | Temperature: 0~50°C | ||||
| Humidity: <90% | |||||
| output | 2.0V AC load resistance 10K | ||||
| size | 140x77x32mm | ||||
| power supply | 4x1.5v AAA7 battery | ||||
| sensor | Piezoelectric vibration sensors | ||||
