Specifications
| Measuring method | F magnetic Induction & NF eddy current |
| Measurement range | 0~2000μm (Miscellaneous Measurement range can be customized) |
| resolution | 0.1μm /1μm |
| Precision | +/- 1 to 3% n or +/- 2.5 μm |
| minimum surface | F: convex 1.5mm/concave 25mm; N: convex 3mm/concave 50mm |
| Minimum measurement area | 6mm |
| Thinnest substrate | 0.3mm |
| Metric/Imperial Conversion | √ |
| Automatic shutdown/low Voltage prompt | √ |
| statistical function | 99 sets of data |
| Operating Environment | Temperature: 0~40 ℃; Humidity: 10~90% RH |
| Power Supply | 4 AA batteries |
| size | 140x77x32mm |
Packing list
Host X1, F/NF Sensors X1, F iron substrate X1, NF aluminum substrate X1, standard (5 pieces) X1, portable case (B04) X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47445/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
