Specifications
| display | 4-Bit digital backlight LCD |
| Standard test scope | 0~1250µm/0~50mil (Miscellaneous Measurement range can be customized) |
| resolution | 0.1 µm (below 100 µm); 1 µm (above 100 µm); 0.1 mil |
| Measurement Accuracy | +/- 1 to 3% n or +/- 2.5 µm or 0.1 mil |
| Thinnest substrate | 0.3mm / 12mil |
| Minimum convex diameter | 4mm / 0.16inch |
| Minimum concave radius | 25mm / 0.98inch |
| Minimum measurement surface diameter | 6mm / 0.24inch |
| Measurement mode | Single measurement and continuous measurement |
| operating conditions | Temperature 0~50 ℃ (32~ 122 ° F); Humidity < 80% RH |
| Power Supply | 2X1.5vAAA 7 #battery |
| size | 129x68x27mm 5.1x2.7x1.1inch |
| Weight | 90G (without battery) 3.17oz |
Packing list
Host X1, wrist rope buckle X1, titanium base (1 piece) X1, aluminum base (1 piece) X1, calibrated diaphragm (1 set) X1, measurement Sensors X1, portable case X1, operation manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47447/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
