Specifications
| Measurement range | ±10000kgf、±98000N、±22000Lbf |
| resolution | 0.01kgf (<100kgf)、0.1kgf (≥100kgf)；0.1N (<1000N)、1N (≥1000N)；0.1Lbf (<1000Lbf)、1Lbf (≥1000Lbf) |
| Precision | Level 0.5 |
| Accuracy | +/- 0.5% FS (range) +/- 1 digital peak |
| unit | kgf, N, Lbf |
| Measured value | Peak, instantaneous value |
| show | Four large LCD, forward and reverse dual display |
| shutdown mode | 10 minutes automatic shutdown or manual shutdown |
| Backlight | Blue Backlight |
| allowable load | 150% F.s (buzzer alarm when it exceeds 110% F.s) |
| Power Supply | 2 AA batteries, or 5V DC Power Supply |
| Operating temperature | 0°C~40°C |
| Operating humidity | < 80% |
| Operating Environment | No source and corrosion medium around |
| Host size | 199mmx76mmx37mm |
| Sensors size | 140mmx65mmx105mm |
Packing list
Electronic tension meter X1, instruction manual X1, portable case X1
After-sales instructions
Warranty days: 365 days
