Specifications
| peak | 395Nm (bottom width 340-420) |
| display | LCD screen |
| Power Measurement range | 2.000mW/20.00mW/200.0mW/cm² |
| Measurement Accuracy | ±5 % |
| resolution | 0.1 mW/cm² |
| Standard line | The line length is 1 meter, and the extension must be customized. |
| Sampling time | About 0.5 seconds |
| temperature | 0-50℃ 32-122F) |
| Humidity | Less than 80% RH |
| Weight | About 200g (including battery) |
| size | Host: 140x77x32 mm Sensors: 59x φ 58mm |
| Power Supply | 4 AA batteries |
| Standard | Host instruction manual portable box |
| optional | Bluetooth adapter and software, RS-232 |
Packing list
Host X1, instruction manual X1, portable case X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47470/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
