Specifications
| Drawdown blade Accuracy | ±3%mm |
| Drawdown blade film thickness | 0~10mm |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Wire rod film thickness | 1~ 571.5μm (Spreader thickness determined according to rod model) |
| Wire rod film Accuracy | ±0.003mm |
| Host Power Supply | 220V 50Hz |
| Dimension | Non-standard customization, subject to the actual order. |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| customizable function | Jet system device, UV solid inclusion device |
| Speed regulation Accuracy | 1mm/s |
| vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
Packing list
Film Applicator X1, doctor blade X1, imported wire rod X1, automatic inking system x1, product manual X1
After-sales instructions
Warranty days: 350 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47478/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
