Specifications
| Measurement range | HLD(170-960),HS (30.6-102.6),HRC (17.9-69.5),HB(19-683),HV (80-1042),HRA(59.1-88),HRB(13.5-101.7) |
| Measurement direction | 360 ° vertical down, diagonal down, horizontal, diagonal up, vertical up |
| Measurement material | Steel and cast steel, alloy tool steel, stainless steel, gray cast iron, ductile cast iron, cast aluminum alloy, copper zinc alloy (brass), copper tin alloy (bronze), pure copper, forged steel |
| error of indication | +/- 6HLD (Type D Impact Device) |
| Indication Repeatability | +/- 6HLD (Type D Impact Device) |
| Upper and lower limit setting range | (170-960)HLD |
| Indication calibrated | Adjustment with indication software |
| Data storage | Up to 600 Measured values (Impact 32~ 1) |
| Interface | USB 2.0 |
| Operating Voltage | 3.7V lithium-ion rechargeable battery |
| Charging Power Supply | 5V/1000mA; Charging time 2.5~ 4.5 hours |
| Working time | About 50 hours; Operating temperature: -10 ℃~ + 55 ℃; |
| Operating Conditions | Storage temperature: -20 ℃~ + 75 ℃; Relative Humidity < 90%; no vibration in the surrounding environment, no strong magnetic field, no corrosion medium and serious dust. |
| exterior size | 131 × 82x30mm (host) |
| Weight | About 0.6kg (main engine) |
Packing list
Host X1, D-type Impact device X1, standard Richter Hardness block X1, nylon brush AX1, small support ring X1, printing paper X1, communication cable X1, charger X1, data processing software CD X1, instruction manual X1, certificate X1, warranty card X1, ABS instrument special case X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47485/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
