Specifications
| detection range | 1-250.0mm |
| Can detect workpiece material | Carbon steel, cast steel, alloy steel, stainless steel, copper, aluminum, titanium and other conductor materials |
| Measurement equipment error range | When the workpiece thickness is < 10mm, the error is +/- 0.05mm; when the workpiece thickness is > 10mm, the error is + (0.01 + H/200) mm (H is the workpiece thickness value) |
| Indication Repeatability | 0.8%(HLD=800) |
| Receive gain | ≤100dB |
| lift-off gap | 0~2.5mm |
| Probe maximum tilt angle | ±25° |
| Probe excitation method | permanent magnet |
| Sound wave type | Shear wave (shear wave) |
| high temperature compensation | Speed of sound automatic compensation function |
| Speed adjustment range of sound waves | 1000-9999m/s |
| waveform display | Positive half wave, negative half wave, full wave, RF wave, envelope wave |
| Power Supply | Built-in lithium battery, Working time is not less than 5 hours |
| Operating temperature range | -10~+50℃ |
| Host Storage Temperature range | 0-+40℃ |
| Host Weight | 250G (with room temperature probe) |
| Dimensions (length × width × thickness) | 176×42×32mm |
