Specifications
| Spreader head | Drawdown blade |
| compound speed | 1-10M/min (slow compounding speed, step-by-step control, adjustable above 0.1m/min) |
| composite width | 100-300Mm adjustable |
| WFT | 0.005-3mm |
| Device size | About 1800X width 800X height 1600mm (customized products are for reference only) |
| maximum discharge | 300mm |
| maximum charge | 300mm |
| Coating size | Max.300mm |
| Air-Cooled Curing Oven | room temperature |
| Curing Oven Length | 1m |
| Curing Oven Power | 1KW |
| Power/Power | 220V/2.5KW |
| motor | Stepper motor |
| Feed trough heating temperature | Room temperature~ 200 ℃ |
Packing list
Host x1, Manual x1, Encasement List x1, Certificate of Conformity x1
After-sales instructions
Warranty days: 365 days
