Specifications
| Volume L | 80L |
| Temperature and Humidity Control Instrument | Programmable platform Controller, touch screen input, Chinese and English switching. Different temperature points can be arbitrarily set according to customer requirements |
| Box structure | This equipment is divided into: high temperature zone, low temperature zone |
| Test area size | 450 * 450 * 400 (width * depth * height) * 2 |
| Test Temperature Impact Range | -40 ℃~ + 150 ℃ (optional programming setting) |
| Temperature range of high temperature box | + 60 ℃~ + 180 ℃ (optional programming setting) |
| Temperature range of cryogenic chamber | 0 ℃~ -55 ℃ (programmable arbitrary setting) Temperature range -40---150 degrees |
| Temperature transition time | 10 seconds (time can be specified) |
| Controller control Accuracy | ±0.2℃ |
| shell material | Sheet metal paint |
| Inner box material | SUS #304 Thickened heat-resistant and cold-resistant stainless steel plate, first-class light panel |
| Thermal Insulation | High density Glass cotton and high strength PU foam insulation materials have good thermal insulation effect |
| box uniformity | ±2 |
| Air supply circulation system | Japanese multi-wing centrifugal Circulating Fan, Japanese motor whole group |
| heater | U-shaped fin type 304 #seamless steel high-speed heating electric heater. |
| Refrigeration compressor | Adopt imported Compressor unit |
| Refrigeration accessories | Table bending center force evaporator, Mar fan, etc |
| Refrigeration method | Use air-cooled or water-cooled heat dissipation (water towers, pipes, the buyer installs them by himself) |
| Sample holder | Hanging Basket |
| Electrical accessories | Domestic well-known brand electrical components |
| wiring method | The company's electronic control wiring method is implemented in accordance with international electrical standards |
| Protection device | Compressor overheating, overtemperature, overload, high Voltage, low pressure, oil pressure, overcurrent, underphase, power failure standby and other alarm warnings. |
| Power Supply | AC380V 50~60Hz 18KW |
| Meet the standard | GB2423 [1] .02 High temperature test method, GB2423 [1] .01 Low temperature test method. |
| Temperature Fluctuation | ±2℃ |
| temperature error | ±2℃ |
| Cooling rate | From room temperature~ -55 ℃ ≤ 60min |
| Power | About 18KW |
| Hanging basket load-bearing | Within 20Kg |
| Cooling mode | air-cooled |
| Sample movement method | Hanging basket lift |
| Temperature measurement | Pt100 platinum resistor |
| control device | The main Controller adopts imported dual-loop high-precision LCD display touch screen temperature Controller |
| Setting Accuracy | Temperature: 0.1 ℃; Time: 1s |
| user program Capacity | 30 × 100 segments |
| operation mode | Program running, constant running |
Packing list
host X1, manual X1, certificate X1, warranty card X1
