Specifications
| Test Chamber Temperature Impact Range | High temperature box: + 50 ℃~ 180 ℃; Low temperature box: 0 ℃~ -55 ℃ |
| Temperature Fluctuation | ±2℃; |
| temperature error | ±2℃; |
| Cooling rate | From room temperature~ -55 ℃ ≤ 60min; |
| Power Supply | 380V±38V50Hz±1Hz |
| Power | About 18Kw |
| Hanging basket load-bearing | Within 20Kg. |
| Volume L | 150L |
| Temperature and Humidity Control Instrument | Programmable platform Controller, touch screen input, Chinese and English switching. Different temperature points can be arbitrarily set according to customer requirements |
| Box structure | This equipment is divided into: high temperature zone, low temperature zone |
| Test area size | 600 * 600 * 420 (width * depth * height) * 2 |
| Exterior size approx. | 1390x2120x1820mm |
| Test Temperature Impact Range | -40 ℃~ + 150 ℃ (optional programming setting) |
| Temperature range of high temperature box | + 60 ℃~ + 180 ℃ (optional programming setting) |
| Temperature range of cryogenic chamber | 0 ℃~ -55 ℃ (programmable arbitrary setting) Temperature range -40---150 degrees |
| Temperature transition time | 10 seconds (time can be specified) |
| Controller control Accuracy | ±0.2℃ |
| shell material | Sheet metal paint |
| Inner box material | SUS #304 Thickened heat-resistant and cold-resistant stainless steel plate, first-class light panel |
| Thermal Insulation | High density Glass cotton and high strength PU foam insulation materials have good thermal insulation effect |
| box uniformity | ±2 |
| Air supply circulation system | Japanese multi-wing centrifugal Circulating Fan, Japanese motor whole group |
| heater | U-shaped fin type 304 #seamless steel high-speed heating electric heater. |
| Refrigeration compressor | Adopt imported Compressor unit |
| Refrigeration accessories | Table bending center force evaporator, Mar fan, etc |
| Refrigeration method | Adopt water-cooled heat dissipation (water towers, pipes, the buyer installs them by himself) |
| Sample holder | Hanging Basket |
| Electrical accessories | Domestic well-known brand electrical components |
| wiring method | The company's electronic control wiring method is implemented in accordance with international electrical standards |
| Protection device | Compressor overheating, overtemperature, overload, high Voltage, low pressure, oil pressure, overcurrent, under-phase, power failure standby and other alarm warnings., |
| Power Supply | AC380V 50~60Hz 18KW |
| Meet the standard | GB2423 [1] .02 High temperature test method, GB2423 [1] .01 Low temperature test method. |
| Weight | 750KG |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47632/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
