Specifications
| way | Double air duct rotary air supply |
| Temperature range | AT+10-300℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1C |
| Temperature Uniformity | ±2.5% |
| Interior | Mirror stainless steel plate |
| exterior | Cold rolled steel plate, surface resistant painting |
| heat insulation material | aluminum silicate fiber |
| heater | Stainless steel heating tube (explosion-proof qualification) |
| Rated power | 5.75KW |
| Exhaust Port | Inner diameter 28mm * 2, top |
| Temperature Control mode | Liquid display dual PID control |
| Temperature setting method | Tap the explosion-proof four-button setting. |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| timer | 0~9999 minutes (or hours), Timer function can be selected (none, thermostatic Timer, running Timer) |
| Operational Features | Fixed-value operation, regular operation, automatic stop, scheduled start |
| Program Mode | optional |
| External connection protection | Adopt explosion-proof flexible connecting pipe set (explosion-proof qualification) |
| Sensors | Explosion-proof armored PT100 (explosion-proof qualification) |
| Additional features | Deviation correction, menu button lock, power failure memory, overlift preventer |
| Explosion-proof level | Ex de mb IIB T4 Gb |
| Inner Dimensions (width * depth * height mm) | 660*760*1250 |
| Dimensions (Width "Depth" Height mm) | 900*960*1840 |
| Packing size (width * depth mm) | 1051'1060'1949 |
| Internal Volume | 625L |
| Shelf load bearing | 15kg |
| Shelf layer | The seventh floor. |
| Shelf spacing | 150mm |
| Power supply (50/60Hz) rated current | AC380V/8.7A |
| Net Weight/Gross Weight kg | 113/137 |
| Shelf | 2 pieces |
| Shelf | 4 pieces |
| Optional Accessories | Explosion-proof barrier, explosion-proof hinge, explosion-proof pressure relief door, explosion-proof seven-inch touch screen instrument (with Linear dispersion, program function), explosion-proof mouse |
