Specifications
| way | Forced circulation of crosswind duct |
| Temperature range | RT+10~250℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1 ℃ |
| Temperature Uniformity | ±2.5% |
| Interior | stainless steel plate |
| exterior | Cold rolled steel plate, surface resistant painting |
| heat insulation material | aluminum silicate fiber |
| heater | Stainless steel heating tube (explosion-proof qualification) |
| Rated power | 4.0KW |
| Exhaust Port | Inner diameter 28mm * 1; top test hole |
| Temperature Control mode | LCD dual PID control |
| Temperature setting method | Tap the explosion-proof four-button setting. |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| timer | 0~9999 minutes (or hours), Timer function can be selected (none, thermostatic Timer, running Timer) |
| Operational Features | Fixed-value operation, regular operation, automatic stop, scheduled start |
| Program Mode | optional |
| External connection protection | Explosion-proof armored PT100 (explosion-proof qualification) |
| Sensors | Adopt explosion-proof flexible connecting pipe set (with explosion-proof qualification) |
| Additional features | Deviation correction, menu button lock, power failure memory, overlift preventer |
| Explosion-proof level | Ex de mb JB T4 Gh |
| Inner Dimensions (width "depth * height) | 600*500*750mm |
| Dimensions (width * depth * height) | 1015*685*995mm |
| Packing size (width * depth * height) | 1220*802*1156mm |
| Internal Volume | 225L |
| Shelf load bearing | 15kg |
| Shelf layer | The ninth floor. |
| Shelf spacing | 25mm |
| Power supply (50/60Hz) rated current | AC220V/18.2A |
| Net Weight/Gross Weight | 81/110kg |
| Shelf | 2 pieces |
| Shelf | 4 pieces |
| Optional Accessories | Explosion-proof barrier, explosion-proof hinge, explosion-proof pressure relief door, explosion-proof seven-inch touch screen instrument (with Linear dispersion, program function), explosion-proof mouse |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47640/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
