Specifications
| way | Decompression, four-wall heating |
| Temperature range | RT+10~250℃ |
| Use vacuum range | <133PA |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1℃ |
| Heating time | 120 minutes |
| Interior | stainless steel |
| exterior | Cold rolled steel plate, surface resistant painting |
| heat insulation material | aluminum silicate fiber |
| heater | Stainless steel heating tube 4-sided heating (explosion-proof qualification) |
| Viewing Window | Bulletproof Tempered Glass |
| Rated power | 2.0KW |
| Temperature Control mode | LCD dual PID control |
| Temperature setting method | Tap the explosion-proof four-button setting. |
| Temperature representation | Measurement temperature display: liquid crystal upper display; set temperature display: liquid lower display |
| timer | 0~9999 minutes (or hours), Timer function can be selected (none, thermostatic Timer, running Timer) |
| Operational Features | Fixed-value operation, regular operation, automatic stop, scheduled start |
| Program Mode | optional |
| Sensors | Explosion-proof armored PT100 (explosion-proof qualification) |
| External connection protection | Adopt explosion-proof flexible connecting pipe set (with explosion-proof qualification) |
| Additional features | Deviation correction, menu button lock, power failure memory, overlift preventer |
| Explosion-proof level | Ex de mb IIB T4 Gb |
| Inner Dimensions (width * depth * height) | 450*450*450mm |
| Dimensions (width * depth * height) | 640*642*796mm |
| Packing size (width * depth * height) | 769*855*923mm |
| Internal Volume | 91L |
| Shelf load bearing | 15kg |
| Shelf layer | 2nd floor |
| Shelf spacing | 185mm |
| suction port | Φ10mm |
| Exhaust Port | Φ10mm |
| Power Supply | AC380V/9.1A (50/60Hz) rated current |
| Net Weight/Gross Weight | 82/105kg |
| Shelf | All Aluminum Shelf 2 Pieces |
| Optional Accessories | Explosion-proof barrier, explosion-proof hinge, explosion-proof pressure relief door, explosion-proof seven-inch touch screen instrument (with Linear dispersion, program function), explosion-proof mouse, Shelf, vacuum pump |
