Specifications
| Measurement range | 0~2.0kgf 0~2000gf 0~19.6N 0~4.4Lbf |
| resolution | 0.001kgf 1gf 0.01N 0.001Lbf |
| Precision | +/- 1.5% or better |
| Wheel spacing | 40mm |
| unit | kgf, gf, N, Lbf |
| Measurement principle | strain gauge |
| Measurement frequency | 16 milliseconds (62.5 sampling/s) |
| Sensing Wheel Offset (MAX Maximum) | 0.2mm |
| overload Capacity | 150% of full scale |
| temperature coefficient | Zero point: less than +/- 0.3% FS/℃ Within range: less than +/- 0.01% FS/℃ |
| display update rate | 0.5, 1.0, 2.0 or 4.0 second display conversion optional |
| Measured value | Current Value, MAX Maximum, Peak, MIN Minimum |
| Roller material | Stainless steel (standard) |
| Maximum speed | 2000m/min |
| operating conditions | Temperature: 0 ℃~ 40 ℃ (32 ° F~ 104 ° F) |
| Power Supply | 4X1.5v AAA AA batteries |
| size | Host: 140mm * 70mm * 31mm |
| Weight | 400G (without battery) |
Packing list
host X1, portable case X1, certificate X1, manual X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47770/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
