AMITTARI MT-200D Gaussian meter, magnetic field Measurement Instrument
SEHigh-precision measurement, automatic zero adjustment, peak hold and unit conversion functions, easy to operate, portable and lightweight, suitable for fast and accurate measurement of DC magnetic fields.
$173.00/set
PromotionLoading...
Coupon
Model：
MT-200D
AMITTARI MT-200D gausometerSPEC
AMITTARI MT-200D gausometerDetails
AMITTARI MT-200D gausometerPacking list
- SKU
- NB047775
- Range
- 0mT~200mT~2000mT
- Precision
- DC, 5% (measurement in uniform magnetic field)
- measured magnetic field
- DC magnetic field (static magnetic field)
- Function Description
- Peak hold function Gs (Gauss)/mT (millitesla) can be switched freely
- DC polarity measurement
- N table anode, S table cathode
- Environmental temperature
- 5℃~40℃
- Relative Humidity
- 20% to 80% (undoubtedly exposed)
- Power supply
- Four AA batteries
- Dimension
- 140mm (L) *73mm (W) *30mm (H)
- instrument Weight
- 180g
- Display mode
- 41/2LCD
- Display unit
- mT/Gs
- standard accessories
- Host (one)
MT-200D
gausometer
High-precision measurement, automatic zero adjustment, peak hold and unit conversion functions, easy to operate, portable and lightweight, suitable for fast and accurate measurement of DC magnetic fields.
Features
Easy to carry and wide range.
Push-button auto-zeroing.
It is easy to operate and the LCD display is clear.
There is a measured value/peak hold, MT/GS unit conversion.
200MT/2000MT range conversion, etc.
Operating Principle
This series of instruments uses sensors made based on the principle of the Hall effect, that is, Hall sensors. There are two types of sensors: horizontal and axial, which can be selected or equipped according to the user's needs; The circuit uses a low-drift amplifier and a high-stability power supply, which is controlled by a microcontroller and displays the measured values on a 4 1/2 LCD.
FAQ
QI want to measure the DC magnetic field, I need a portable instrument, do you recommend it?
A
MT-200D Gauss meter uses Hall Sensors, which specializes in measuring DC magnetic field, weighs only 180 grams, is easy to carry, and is suitable for on-site rapid detection.
QCan this Gaussian meter measure motor magnets? How to choose?
A
Yes, MT-200D has a range of 0-2000mT, covering the range of common permanent magnets. It has axial/lateral probes to choose from. When measuring the motor, the probe is selected according to the magnetic field direction. The operation is simple, with peak holding function, and it can capture the maximum magnetic field value.
QCan the unit be switched when the instrument measures the magnetic field? Is the operation complicated?
A
Support one-click switching of mT and Gs units, button-type automatic zero adjustment, LCD screen directly displays the value, no professional training is required, just follow the instructions, suitable for daily testing of production lines or laboratories.
