YUEPING DC-2015 Thermostatic Water Bath Temperature range -20 ℃~ 100 ℃

DC-2015

Thermostatic Bath

Temperature range -20~100 ℃, Temperature Fluctuation 0.05 ℃, Temperature resolution 0.01 ℃, working tank volume 15L, slot opening size 235 * 160 * 200mm, working bath depth 200mm, Temperature control mode Microcomputer temperature control, PID adjustment, circulation mode Internal/external circulation

Low temperature thermostatic sink DC-2015Introduction

Yueping Low Temperature Constant Temperature Tank DC-2015 is a Low Temperature Circulating Bath with a temperature range of -20°C~100°C and a power of 2KW.It adopts PID automatic control, and the temperature control accuracy is high.The cryogenic thermostatic tank DC-2015 has a tank depth of 200mm and a volume of 15 liters.

Parameters

Features

1、Low temperature thermostatic sink DC-2015It is widely used in chemical, petroleum, medical, biological, physical chemistry, metrology, colleges and universities, electronic instruments, scientific research institutions and other fields for experiments, testing and enterprise production in a place with controlled cold and heat and uniform temperature to carry out constant temperature tests or tests on test samples or produced products.

2. The constant temperature control system adopts PID automatic control, LED liquid crystal digital display, and real-time observation of data.

3. The external circulation pump can output the constant temperature liquid in the tank to the outside, establish the second constant temperature field outside the tank, and expand the scope of use.

Optional

♦ RS232 or RS485 communication interface can be selected to realize data transmission for long-distance control.

♦ It can be equipped with an optional programmed temperature control system, which features:

 Large LCD display, software program control, editable time/temperature curve.

 Multi-segment temperature and time programs can be programmed to control the heating, constant temperature and cooling process, and the heating rate and cooling speed can be set and automatically controlled according to user requirements.

 Up to 30 temperatures/time periods can be programmed and stored, and each program can be set to run time of 0~9999 minutes.

 Multiple parameter setting methods: convenient and fast input keys, shift keys, additional keys, and subtract keys, set temperature/time period and other advanced control parameters, or directly adjust the stored temperature/time setting program.

Main application areas

Analytical instruments: spectrometer, mass spectrometer, viscometer, polarimeter, fermentation device, rotary evaporator.

Vacuum acquisition and**: molecular pump, diffusion pump, cooling blanket, X-ray machine, nuclear magnetic resonance accelerator.

Industrial equipment and others: laser equipment, vacuum coating equipment, biology, molds, machine tools, vacuum furnaces, welding machines, reactors.

Packing list：1 host, 1 power cord, 1 rubber tube, 1 cover plate, 1 manual, 1 certificate/warranty card

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
