Specifications
| Coating method | Rod |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 640*310mm |
| Mayer Rod Thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Mayer Rod Accuracy | ±0.001mm |
| Effective coating Area | 400 * 280Mm (can be customized) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Power | 2000w |
| Heating Temperature range | RT +~ 260 ℃ (graphene heating) |
| Temperature Uniformity | ±3℃ |
| Dimension | 660*420*430mm |
| Operating language | Chinese (can be customized in English) |
Packing list
Host X1, manual X1, fixture X1, imported wire rod X1, certificate X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47845/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
