Specifications
| Photosensitive chip | CMOS; 1280 * 1024; 1.30 million pixels |
| screen | 7-Inch LCD touch capacitive screen 1280 * 720 150DPI |
| magnification | 4X lens X lens X lens (std.); 50X (optional) |
| Light source | coaxial light |
| Communication interface | USB; wireless network interface card |
| Storage Capacity | 4GB |
| Operating system | Android |
| Measurement Accuracy of length | +/- 0.5um length measurement |
| Measurement Accuracy | +/- 1a height measurement |
| Battery Capacity | 3000mAh lithium battery |
| Battery charging | Voltage 3.7V; AC transformer |
| power consumption | Work continuously for more than 2 hours |
| Z-direction maximum range | 4000um |
| Dimension | 300mm*123mm*220mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47908/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
