Specifications
| sampling | 80MSPS |
| Bandwidth | 2.5MHz～6MHz |
| launch | ±600V_400Hz_125ns |
| gain | Automatic 0~96dB, step distance 1dB |
| Measurement Accuracy | ±0.01mm |
| Speed of sound | 400～9999 m/s |
| effective range | 1.0～640 mm |
| average grade | L, M, H three gears adjustable |
| distance | 5Mm (aluminum), 4mm (carbon steel), 3mm (stainless steel) |
| Measurement range | Measurement carbon steel - 1X: 160mm 2X: 320mm 3X: 640mm |
| Measurement type | Aluminum, copper, iron, carbon steel, cast steel, alloy steel, stainless steel, titanium alloy and other metal materials |
| Measurement channel | Thin, general purpose, bar |
| Measurement mode | Single echo (I-E), double echo (E-E) |
| search mode | Frontier - Frontier, Crest - Crest, Crest - Frontier |
| auxiliary feature | Auto freeze, auto gain, auto sleep, A scan waveform display |
| correction function | Gate height adjustment, delay blanking adjustment, manual gain adjustment, Speed of sound calibrating, high temperature compensation |
| communication | RS-485 or USB2.0 |
| Charger | 5V2A, standard Type-C interface |
| Display | 1.47 inch 320 × 172 IPS_LCD |
| Body size | 178.4 mm x 42 mm x 32 mm |
| battery life | 3.7V 3400mAh lithium battery, battery life for 6 hours |
| Bare metal Weight | A Metal shell: 358g B Injection molding shell: 255g C Injection molding + quick release: 289g |
| probe | With high temperature probe 800 ° |
Packing list
host X1, high temperature probe x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/47983/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
