Specifications
| Lighting method | Transmission: D/0 (diffuse illumination, 0 ° direction reception); approximate CIE15 specification 0/0 (parallel light illumination/0 degree reception); meets standards: ASTM D1003/1044, CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ASTM E308, DIN5033 Teil7 |
| Integrating sphere size | Φ154mm |
| Light source | 360~780Nm Combined LED Light source |
| spectroscopy | Concave grating |
| Sensor | 256 pixel dual array CMOS image sensor |
| Measurement Wavelength range | 360~780nm |
| wavelength interval | 10nm |
| Bandwidth | 10nm |
| Transmittance range | 0~200% |
| Measurement aperture | Transmission: φ 25.4mm/φ 4mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,Musell,s-RGB,HunterLab,βxy,DIN Lab99 |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99,ΔE(Hunter) |
| Other chroma metrics | Haze (ASTM D1003/1044), Transmittance T, WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), TI (ASTM E313, CIE/ISO), Isochromatic Index Mt, colour fastness, discoloration fastness, Absorbance, APHA/Hazen/Pt-Co (Platinum Cobalt Index), Gardner Index, Saybolt (Seibert Index), ASTM D1500 color code, Chinese Pharmacopoeia chroma |
| Observer Angle | 2°/10° |
| Observational Light source | D65,A,C,D50,D55,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,DLF,TL83,TL84,TPL5,U30 |
| show | Light spectrum plots/data, sample chromatic values, color difference values/plots, chromaticity plots, Color simulation, pass/fail results, Color bias |
| Measurement time | About 1.5s |
| Repeatability | Spectral transmittance: test transmission reference white standard deviation within 0.05% (400~700nm: within 0.04%): chromatic value: φ 25.4mm, Delta E * ab within 0.03 (after instrument preheating correction, at intervals of 5s measurement of transmission reference white 30 times average |
| stand-alone difference | φ 25.4mm, Delta E * ab within 0.2 (the average measurement value of the original 5 standard transmission color plates) |
| size | Length X width X height = 370X300X200mm |
| Weight | About 9.6kg |
| Power Supply | DC 24V, 3A power adapter Power Supply |
| Light source lifetime | More than 3 million measurements in 5 years |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port |
| Store data | 5000 master standards, 20,000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Temperature range | 0~40℃（32~104°F） |
| Temperature range | -20~50℃（-4~122°F） |
| Standard Accessories | Power adapter, manual, quality management software (official website download), data cable, reflection whiteboard, reflection black cylinder, transmission blackboard, 25.4 caliber, transmission test fixture assembly, micro-hole (4mm) transmission test fixture assembly |
| Optional Accessories | micro printer |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48064/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
