Specifications
| Friction method | swirl/ spin |
| Frictional contact form | face |
| Meet the standard | GB/T3810.6、GB/T12988、ISO10545-6 |
| Control system | PLC |
| Operating interface | Color 7-inch touch screen, switch between Chinese and English |
| Rotation speed of grinding wheel | 75 +/- 4r/min constant |
| Standard grinding wheel diameter | 200 +/- 0.2mm, thickness 10 +/- 0.1mm, Hardness HB500 or more; (applicable to GB/T3810.7-2006) |
| Optional grinding wheel two diameter | 200 +/- 0.2mm, thickness 70 +/- 0.1mm, Hardness HB500 or more; (applicable to GB/T12988-2009) |
| Specimen size | 100mm×150 mm |
| Storage hopper Volume | Greater than 5L |
| Optional abrasive | Its particle size is F80 white molten aluminum oxide specified in ISO8486-1986 |
| test time | Can be preset, touch screen digital display |
| Equilibrate Weight | The customer needs to provide the sample Weight. |
| Dimension | 980*550*820mm |
| Electricity requirements | 220V,20A,50hz |
| Air source requirements | 0-0.4 mpa customer |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
