Specifications
| Scribing traverse speed | 0-25Mm/s, adjustable |
| Power supply Voltage | 220V/50Hz |
| Dimension | 380 * 300 * 180mm (length * width * height) |
| Control system | PLC + touch screen |
| Operating interface | Color 7-inch touch screen, switch between Chinese and English |
| Drive mode | Stepper motor drive |
| Limited itinerary | 0-85Mm (optional Miscellaneous stroke can be customized for free) |
| number of trials | 0-9999 times, can be preset |
| Device configuration | Automatic stop function after scratch contact (electrode device) |
| Contact limit angle | 18 degrees |
| Contact Spherical Transition Dimensions | R6 |
| Scratch spacing | 0-50Mm, adjustable |
| test size | About 150 * 100mm range |
| work surface | 360 ° swirl/spin |
| Scratch pressure | Standard 10N +/- 0.5N, quantity 1 piece. Optional with 20N Weight and 30N +/- 0.5N scratch pressure |
| Scratch needle | R0.25 +/- 0.02mm Optional Miscellaneous Specifications |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
