Specifications
| supply Voltage | AC220V，50Hz |
| Rotation speed | 0~10000rpm |
| Acceleration | 100~5000rpm/s |
| Rotation speed resolution | 1rpm |
| single step time | 3000s |
| Cavity material | Acrylic material, easy to observe the spin coating state |
| lid | PP material with injection tube bracket |
| Operation mode | 7 inch high definition LCD touch screen |
| Epoxy method | Manual glue drop, optional precision syringe pump |
| Linear dispersion | Linear dispersion 5 segments each, a total of 5 Linear dispersions can be stored |
| Extraction port | φ 8mm quick screw interface |
| Machine size | 290mm×365mm×260mm |
| Machine Weight | 22kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48299/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
