Specifications
| Control system | PLC |
| Operating interface | Switch between Chinese and English; |
| test software | Free remote upgrade |
| injection area | All samples are set to the injection area. |
| injection time | Can be set for 0-999 seconds and set the time pause time during injection |
| funnel | Made of stainless steel, about 0-10 kg of spray medium can be installed |
| 3D test chamber | SAE 45 ° Impact Box and VDA 90 ° Impact Box 2-in-1, no need to replace, 90 °, 54 °, internal anti-collision soft material |
| Vibration system | Equipped with pneumatic vibration system |
| jet medium | Steel balls, pebbles, grit, etc |
| Specimen size | Width ≤ 195mm Thickness ≤ 35mm Length ≤ 240mm (can be equipped with different fixtures and sample sizes according to different products) |
| Jet speed | Adjustable 0-1MPA |
| emission | Adjustable, the opening can be adjusted arbitrarily |
| crushed stone diameter | 6mm |
| Pressure adjustment range | 0-1000kPa |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48307/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
