HUITAO HT-565 coating fabric low temperature impact test instrument, low temperature brittleness
SE
HT-565
huitao HT-565 Coating fabric low temperature impact test instrumentSPEC
huitao HT-565 Coating fabric low temperature impact test instrumentDetails
huitao HT-565 Coating fabric low temperature impact test instrumentPacking list
- SKU
- NB048309
- Refrigeration method
- Cascade refrigeration
- Cold head size
- 190×150×120mm
- cold bath Volume
- 200×160×158mm
- Temperature range
- RT+~-70℃(@25℃)
- Temperature Fluctuation
- ±0.5℃
- Temperature Resolution
- 0.1℃
- Impact velocity
- Test speed of 200 +/- 20cm/S at and within 5m after Impact
- Power Supply
- AC220V±10V,50Hz
- Sample clamping Capacity
- 9 can be clamped at a time
- Impact device
- Consists of 25 diameter optical axis and CounterWeight Weight
- Dimension
- 750×520×1350mm
use
This instrument is suitable for, FZ01007, GB/T5470-2008, GB/T8815-2008JT1037-2004 standards, for the determination of fabric coatings, soft plastics (polyethylene cables, wires and cables, etc.) embrittlement temperature, it is to determine the low temperature of plastic under the specified conditions when the sample is damaged by impact, that is, the brittle temperature, and the performance of non-rigid plastics and other elastic materials under low temperature conditions can be compared and signed. Advantages and disadvantages of temperature and low temperature performance.
Basic configuration
This instrument uses a two-stage refrigerator composed of imported compressors to replace the traditional carbon dioxide dry ice coolant. The cold bath temperature is controlled by the touch liquid crystal temperature controller, the temperature control is accurate, and it is equipped with the freezing time arrival timing alarm device, the time is accurate, it is composed of an impact device (using the accelerated vertical impact method), a refrigeration device, a cold bath stirring device and a PL program temperature control device, with novel design, compact structure and easy to use.
