Specifications
| Heating power | 3000W |
| Total Power | 3100W |
| Coated suction plate size | 360mm X 200mm |
| Film thickness Accuracy | ±0.01mm |
| Drawdown blade Moulding machine | 300Mm wide |
| rewinding mechanism | Rotation speed of rewinding and unwinding mechanism is adjustable from 1~ 400mm/min, and the mechanism adopts feedback adjustment, which can automatically correct Rotation speed deviation |
| Top UV | Wavelength 365nm |
| Temperature control Accuracy | ±1℃ |
| Machine size | 1245Mm X 500mm X 270mm (close protective cover) 1245mm X 550mm X670mm (open protective cover) |
| Net Weight | About 100kg |
| vacuum pump | Mechanical pump FY-4C-N |
| pumping rate | 4m3/h |
| Exhaust port | φ 8 quick screw joint |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48315/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
