Specifications
| maximum test force | 20KN |
| Testing machine level | Level 0.5 |
| Load Measurement Range | 0.4%～100%FS |
| Indication relative error | ≤±1% |
| Test force resolution | 1/+/- 500000F. S (full resolution unchanged) |
| Deformation Measurement Range | 0.2%～100%FS |
| Force-controlled rate adjustment range | 0.005%～5%FS/S |
| Force control rate control Accuracy | When the rate is < 0.05% FS, it is within the set value of +/- 1%; when the rate is ≥ 0.05% FS, it is within the set value of +/- 0.5%; |
| Deformation rate adjustment range | 0.005～5%FS/s |
| Deformation rate control Accuracy | When the rate is < 0.05% FS/s, it is within +/- 1% of the set value; when the rate is ≥ 0.05% FS/s, it is within +/- 0.5% of the set value; |
| Displacement rate adjustment range | 0.05~ 500mm/min (adjustable) |
| Displacement speed control Accuracy | Within +/- 0.5/1% of the set value; |
| Constant force, constant deformation, constant displacement control range | 0.5%～100%FS |
| Constant force, constant deformation, constant displacement control Accuracy | When the set value is ≥ 10% FS, it is within +/- 0.5% of the set value. When the set value is < 10% FS, it is within +/- 1% of the set value |
| effective test span | 400mm |
| Effective stretch height | 700mm |
Packing list
Host X1, 2T including standard fixture X1, computer X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48328/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
