Specifications
| optical path structure | D/0° |
| lighting source | Light spectrum LED light source |
| Wavelength range | 400-700nm |
| wavelength interval | 10nm |
| Measurement caliber | 5mm/14mm |
| Measurement conditions | D65 light source/field of view 10 °; A light source/field of view 2 °; C light source/field of view 2 ° |
| Measurement time | About 3s |
| Measurement parameter | Haze, light transmitance, CIE Lab, Lch, Yxy, Light spectrum light transmitance, clarity, turbidity, platinum cobalt chroma |
| Light transmitance resolution | 0.01% |
| Light transmitance Accuracy | Better than +/- 1% |
| Light transmitance repeability | ≤ 0.03 (after preheating correction, 30 standard deviations of the standard haze sheet with an interval of 3s measurement of about 30 haze) |
| Haze/clarity resolution | 0.01% |
| Haze/clarity Accuracy | Better than +/- 2% |
| Haze/clarity, sexual repeability | ≤ 0.03 (after preheating correction, 30 standard deviations of the standard haze sheet with an interval of 3s measurement of about 30 haze) |
| Color difference repeability | Standard deviation Delta E * ab, within 0.03 (measurement conditions: after preheating correction, the average value of 30 white glass measurements at intervals of 3s) |
| Turbidity resolution | 0.1NTU |
| Turbidity range | 0-1000NTU |
| Turbidity Accuracy | ≤ +/- ( 5% H + 1NTU), H is the standard value |
| Platinum cobalt chroma resolution | 0.1 |
| Platinum cobalt chroma range | 0-1000 |
| Platinum cobalt chroma Accuracy | ≤ +/- ( 5% H + 1), H is the standard value |
| Display | 7 inch 1024 * 600 dot matrix IPS smart screen |
| system language | Simplified Chinese, English |
| Data Interface | USB(Type-C) |
| Operating temperature range | 0-45 ℃, 0-85% RH (no condensation) |
| Storage temperature range | 25-55 ℃, 0-85% RH (no condensation) |
| Instrument Dimensions | Length 211mm × Width 264mm × Height 360mm |
| instrument Weight | 5300g |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
