Specifications
| Motor Power | 22kw |
| Speed range | 0~1450 rpm |
| Lifting stroke | 1200mm |
| Effective Volume of sand grinding basket | About 20L (with filtrate cover, turbine suction) |
| dielectric diameter | 1.8~2.5mm |
| Barrel Volume | 500L |
| Dimension | Subject to actual customization |
| Power Supply | 380V |
| Weight | 1200kg |
| Lifting method | Hydraulic lift (pump station with lift limit switch) |
| Processing Capacity | 200~800L |
| Hydraulic Power | 1.1kw |
| Chill down cylinder | 500Mm stainless steel double-decked chilled down cylinder |
| Inner cylinder material | Inner cylinder sus304, outer 304 stainless steel, with dust cover |
| Is it explosion-proof? | Fully explosion-proof |
| Motor quality assurance | 3 years |
| Spindle grinding sleeve | Manufacturer customized PTFE removable sleeve, wear-resistant, fast heat dissipation |
| Spindle material | Solid stainless steel forging treatment |
| Grinding basket material | SUS304 high frequency quenching |
| Filter plate | Wire cutting |
| inlet and outlet | DN25 |
| Discharge port | DN50, national standard silk port |
Packing list
Grinder x1, 500L stainless steel barrel x1, floor-to-ceiling distribution cabinet x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48443/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
