Specifications
| Effective application width | Max.300mm |
| Coating speed | 0~20M/min adjustable |
| Host Power Supply | 220V/2.5KW |
| Dimension | About 1800 * 800 * 1600mm |
| compound speed | 1~10m/min |
| Composite Accuracy | 0.5mm |
| composite width | 100~300Mm adjustable |
| Thickness of glue | 0.005~3mm |
| maximum discharge | 300mm |
| maximum charge | 300mm |
| Drying Temperature range | Room temperature~ 200 ℃ |
| Drying channel length | 2m |
| Drying Power | 1KW |
Packing list
Film Applicator x1, film device x1, drying device x1, rewinding and unwinding device x1, deviation correction device x1, bonding device x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48489/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
