Specifications
| Spreader process | Unwinding → double roller painting film → drying → fitting → deviation correction → winding |
| Coating method | Double roller painting film |
| Thickness range | 0.001-2mm |
| Film Accuracy | ±5% |
| Graduation | 0.001mm |
| percentile | digital display |
| Coating speed | 0~20M/min adjustable |
| Unwinding outer diameter | 300mm |
| Effective application width | ≤300mm |
| Roll surface length | 450mm |
| Oven length | 2m |
| Oven Temperature range | RT+~150℃ |
| winding outer diameter | 400mm |
| Effective application width | ≤300mm |
| compound speed | 1~10m/min |
| Composite Accuracy | 0.5mm |
| composite width | 100~300Mm adjustable |
| Outer diameter of winding air expansion shaft | 3 inches. |
| Winding outer diameter range | ≤300mm |
| Dimension | 2280Mm * 680mm * 1600mm (subject to actual customization) |
| Host Power Supply | 380V/2KW |
Packing list
Film Applicator x1, film device x1, drying device x1, rewinding and unwinding device x1, deviation correction device x1, bonding device x1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48491/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
