Specifications
| Coating Method | Bar Spreader |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 1040*530mm |
| Effective coating Area | 800 * 500Mm (can be customized) |
| Film Film thickness | Controlled by bar, with high Accuracy import bar |
| Meyer rod coating Accuracy | ±0.003mm |
| power | 400w |
| operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimensions | 1060*640*430mm |
| Weight | Subject to the actual product |
| optional feature | Drawdown blade, heating, Vacuum chuck |
Packing list
Automatic Film Applicator x1, bar x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/4855/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
