Specifications
| number of channels | 10 channels |
| Probe type | Type K, N, B, S, J, T, R, E (optional) |
| Temperature Measurement Range | -40 degrees to 1370 degrees |
| Temperature measurement Accuracy | ±1 ℃ |
| Sampling Frequency | 0.2~ 200.00 seconds |
| resolution | 0.1℃ |
| Power supply Voltage | DC3.7V~DC4.2V |
| data transmission | Wired transmission/wireless transmission (optional) |
| continuous testing | Can be tested multiple times, storing up to 16 sets of data |
| startup mode | button start, delayed start, temperature start |
| Instrument temperature resistance | 70-80 ℃ (Recorder Maximum Internal Operating temperature) |
| Instrument power consumption | 12mAh |
| Battery | lithium battery |
| Wireless Frequency | 1.0 to 100.00 seconds (optional) |
| stop mode | Press the button to stop. |
| Total Memory Capacity | 4194304 data points |
| Battery level | 800MA |
| Calibrated mode | Voltage calibrated, temperature calibrated |
| Measurement time | With heat insulation box, it is 300 degrees, 35-40 minutes. |
Packing list
Furnace temperature tester x1, heat insulation box x1, software x1, Thermocouple x10, communication data cable x1, manual x1, high temperature tape x1, high temperature gloves x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48577/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
