Specifications
| Coating Method | Bar + split drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum chuck + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Effective coating Area | 300 * 200Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Meyer rod coating Accuracy | ±0.001mm |
| Drawdown blade Coating thickness range | 0~4500μm |
| Drawdown blade material | High quality alloy steel |
| Drawdown blade application width | 100mm |
| Drawdown blade Spreader Accuracy | ±0.002mm |
| Vacuum chuck size | 300 * 200Mm (can be customized) |
| Vacuum Aperture | Φ0.8mm |
| Vacuum hole pitch | 20*20mm |
| Pumping Speed | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Heating mode | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Heating Temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Standard trend gap | 0.05Mm-0.08mm (can be customized up to 3mm) |
| Air knife Accuracy | 0.01mm |
| Reading method | Scale value |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Power | 1800w |
| Operating language | Chinese (can be customized in English) |
| Dimension | 550*210*340mm |
| Weight | Subject to the actual product |
Packing list
Film Applicator X1, External vacuum pump X1, split drawdown blade X1, imported bar X1, fixed bracket air knife x1, product manual X1
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48580/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
